Industrial Precision Balance
● Backlite LCD Display
Customized, large, attractive LCD with multiparameter display illuminated by white backlite.
● Bi directional RS 232 interface
RS 232 port with selectable baud rate 4800,9600. Various interface formats adopting this Balance in a setup to replace any other leading international Brand Balance. Can be configuered for an USB interface using optional RS232 to USB converter.
● GSM function
GSM function for paper & cloth quality checking.
● Multiple Weighing Units
Grams, Ounces, Troy Ounces, Carats, Mommes, Pennyweights, Grains, tola, Mesghal, Chinese taels.
● Percentage Weighing
Display of Reference weight, sample weight, % of sample with respect to reference weight
● Piece Counting
Parts calibration using preset quantity of samples or programmable quantity. Automatic count
● Fill Mode
1 set point – Indication when sample weight exceeds the set limit.
2 set points – Indication when the sample weight is between the lower & upper limits.
Storage of maximum 200 samples.
● Multiple Printing Mode
0,1,2,3 modes for various formats. Pause in case data storage capacity in a Printer is less.
● External Calibration
Using preset weights.
Known weights can be corrected to + 15 counts.
● Response Time:
User selectable – Slow / Normal /Fast.
● Stability Band Width
Stability indicator appears on display with counts variation + 1, + 2, +3, + 4.
● Auto Zero Tracking
User selectable 0,1,2,3
● Return to Zero Tracking
● Display Updation
Speed setting : Fast / Normal.
|Sl.No.||Capacity||Resolution||Accuracy||Platter Size (mm)||Platter Material|
|1||1.5 kg||1/30000||0.05 g||161.3(dia)||6.5 (H)|
|2||3 kg||1/30000||0.1 g||302(L)||227(W)|
|3||6 kg||1/30000||0.2 g||302(L)||227(W)|
|4||15 kg||1/30000||0.5 g||302(L)||227(W)|
|5||30 kg||1/30000||1 g||302(L)||227(W)|
@Gram Weight Scale @Gram Balance @ Gram Weight Scale @ Gram Balance
Taring Range : Up to full capacity
Response time : 3-5 seconds
Power Req : 90-250V, 50/60Hz, 10 Watt
Operating Temperature : 10 to 45 deg C
Optional Features :
* RS 232 to USB interface converter.
* ISO GLP compliance.
* Real time clock (RTC).
* Weigh below hook for density determination.
* Software for SQC (Statistical Quality Control)for Pharmaceutical Industries.
* Vacuum fluorescent display (VFD).
